Challenger CL20-2 20K Heavy Duty Two Post Lift, Extended

Challenger CL20-2 20K Heavy Duty Symmetric Two post lift, Extended

Made in USA

Challenger CL20-2 20K Heavy Duty Symmetric Two post lift, Extended

SKU: CHL-CL20-2R From $28,150.70
Save $3,099.29

Estimated Lead Time:

Part No: CHL-CL20-2R

Quantity

SHIPPING INFO

Free Shipping

Ground Shipping to Lower 48 States
Alaska, Hawaii, & any/all US territories & international orders are excluded.

Items that ship for FREE via LTL Freight do not include any accessorials such as liftgate, Call before delivery, etc., as well as, any residential fees, limited access delivery fees, inside delivery fees, etc.

ACCESSORIES

DOWNLOADS

Related Categories: ALI Certify Lifts Automotive Lift Challenger Lifts Shop Equipment Two Post Lifts

PRODUCT INFO

CL16 CL20 Sale Sheet

CL16 CL20 Spec Sheet

CL20 User Manual

Challenger Lifts Warranty Information

Challenger Foot Pad Assembly Sheet

The Challenger CL20-2 is a 20,000-pound capacity two-post lift perfect for fleets that need a reliable and durable lift with a bit more height than the standard CL20. It is designed to meet ALI/ANSI safety standards and is built to withstand the toughest of fleet maintenance. The CL20-2 features a single-point air actuated lock release, oversized 5" diameter steel pulley, and heavy-duty 3/8" cable. It also has a 60" lifting carriage design, adjustable width, and symmetrical design for easy access to the vehicle's interior. Dual integrated rubber door guards prevent door damage.

Features:

Capacity: 20,000 lbs.
Extra 2 feet Extended Model
Meets ALI/ANSI safety standards
Built to withstand the toughest of fleet maintenance
Single-point air-actuated lock release
Oversized 5" diameter steel pulley
Heavy-duty 3/8" cable
60" lifting carriage design
Adjustable width and symmetrical design
Dual-integrated rubber door guards

Specs:

Lifting Capacity: 20,000 lbs.
Lift Configuration: Symmetric
Arm Configuration: 2-Stage Front/Rear
Max Load Per Arm: 5,000 lbs.
Rise Height (Max. with Stack Adapters): Min. 76.6in, Max 84.6in
Overall Height Options: 186in, 192in, 198in
Overall Width Options: 166.75in, 160.75in, 154.75in
Drive-Thru Clearance: 104.25in, 110.25in, 116.25in
Floor to Overhead Switch: 179in, 185in, 191in
Arm Reach: Min. 38.5in, Max. 62in
Screw Pad Height: Min. 6.2in, Max. 7.6in
Between Columns: 120in, 126in, 132in
Motor / Voltage2: 3HP, 1Ph, 60Hz, 208/230v
Air Supply Required: 90-120 psi
Rise Time: 62s
Min. Ceiling Height Required: 15ft 8in, 16ft 2in, 16ft 8in
ALI Certified: Yes

Ref No
CHL-18002 (Obsolete Model)
CL16-2 (16K Capacity Model)
CL20 (Standard Model)

Application:

Oil changes
Tire rotations
Brake repairs
Engine repairs
Transmission repairs
Bodywork
Painting
Other maintenance tasks

Business
Fleet Maintenance
Automotive Repair

Includes:

B12162S-12 Screw pads
4in & 8in Stack adapters
Organizer racks with hardware

Optional:
10317 - Reducer bushing kit
10333 - Sprinter adapter kit
- 2 x pin adapters
- 2 x cradle adapters (for 15000-3S series only)
B10264A - Air/electric workstation with filter/lubricator/regulator
B99700 - Tire Tool Manager Work Station with filter/lubricator/regulator
